JK MINI CRANE 300

(JKM 300)


The JK MINI 300 CRANE is a heavy-duty mini crane designed for reliable vertical lifting in mid to high-rise construction projects. With a 300 kg lifting capacity and a reach of up to 120 meters, it is ideal for hoisting cement bags, bricks, concrete pans, and steel to upper floors quickly and safely. Its 360° boom rotation offers excellent flexibility, especially on crowded or partially developed sites where precise material placement is critical.

Powered by a robust 3 HP Crompton motor and built for continuous on-site use, the JK MINI 300 enhances productivity while reducing manual labor. Easy to install and operate, it’s a dependable lifting solution that combines strength, control, and long-term durability in one rugged machine.

SPECIAL FEATURES

  • No Foundation Required
  • Self-Balanced with Smart Counter Weight System
  • Simple Operation
  • Detachable Parts for Portability
  • Installed Quickly

MINI CRANE SAFETY FEATURES

  • Certified Wire Rope
  • Boom Rotation Locking System
  • Tested Bucket Chain
  • Tested with Full Load

Product Details

Model No. JK MINI CRANE 300
Capacity 300 Kg
Height 30 – 120 Meters
Boom Length 6.5 Ft
Rotation 360°
Prime Mover 3 HP Crompton Motor
Wire Rope 10 mm, 6x36 Usha Martin
Bucket Size L750 x W750 x H342 mm
Bucket Volume 0.12 Cu.M
Overall Dimensions L3785 x W685 x H1980 mm
Weight 700 Kg

OPTIONS

Boom: 3.5 / 8 / 10 / 12 Ft Length – Z Type
Bucket: Sturdy / Bottom Discharge / Tilting / Square / Wheeled
PrimeMover: Single / Three Phase Motor / Diesel Engine
Auto Rewinding System
Auto Mechanical Brakes on Power Failure
Customizable Wire Rope Length
Limit Switch with Starter
Mobile Mini Crane with Pin Type Jack System
Data, features and illustrations are not binding and may be altered without any notice.
