SAFARI MULTI FUNCTION HOIST

(Safari TH-R 1000)

All Products

SAFARI MULTI FUNCTION HOIST

(Safari TH-R 1000)


The SAFARI MULTI FUNCTION HOIST is a high-performance multi-function hoist designed for lifting construction materials to elevated floors with speed and safety. With a net carrying capacity of 800 kg and a vertical reach of up to 70 meters, this hoist is ideal for high-rise building sites, structural works, and material shifting in complex RCC projects.

Powered by a 12.5 HP electric brake motor with a gearbox and operated via a remote control panel, the TH-R 1000 ensures smooth and controlled lifting. It features a strong box tower structure with wall ties and foundation support, ensuring stability during continuous operation.

The hoist supports multiple bucket types including concrete, re-bar, and general-purpose carriers—making it a versatile solution for contractors who need reliable vertical transport on demanding job sites.

SPECIAL FEATURES

  • Emergency Cutoff Switch at Panel and on Wired Remote Control
  • Magnetic Safety Brake in Motor
  • Fall Arrest Arm Type
  • Dual Limit Switch for Power Cutoff

Product Details

Model No. TH-R 1000
Gross Load 1000 Kgs
Net Carrying Capacity 800 Kgs
Prime Movers 12.5 HP Electric Brake Motor with Gear box
Mode of Operation Remote control panel box with cable (suitable length for working)
Wire Rope 12 mm, 6x36 Usha Martin
Speed 30 Mtr./Min
Height Up to 70 Mtr.
Bucket Material Bucket / Concrete Bucket / Revolving Re-bar Bucket
Bucket Size 1400 x 800 x 610 mm
Mast Size Square 500 x 400 x 1500 mm
Structure Box Tower with bottom foundation platform and wall ties at suitable length
Data, features and illustrations are not binding and may be altered without any notice.
